Outside Size (mm)

7000×5250×3370

Front Door(mm)

3000(w)×2600(H)

Inside  Size(mm)

6900×3900×2650

Total Power(km)

10+30kw

Wallboard

EPS (epispastics polystyrene)Colorful Steel Skin Boards 0.326mm, 50mm Thick, density 12kg/m2 ,Tongue & Groove Style, Compound Construction, Aluminum-alloy Frame. Anti-flame and Heat-Insulation, Galvanized steel roof panel

Basement&Ramp

Galvanized Steel Sheet and Square steel pipe assembling, Grid &embossed plate floor, Three embossed steel ramps.inner 1m Ramp,outside 1m Ramp ,ramp is 3m*1m.

Inhaling Ventilator

Blower capacity:  22000m3/h,Power:        4kw/set,Quantity: 2 sets

Air Volume: 22000m³/h; Air Speed: 0.35m/s, Air Recycling times:280 times/h

Outlet

Ventilator

No

Purification System

Dual Filtering Structure, The Primary Filter Can Capture Granules Larger than 10μm. Ceiling Filter Capture Granules Bigger than 4μm. Its filtering rate reaches 98%. air pressure balance gauge, TSP≤1.4mg/m³

Heating System

30pc Infrared heating tub Max Temp:80^。C, Heating Time: 8-10min(50-60℃),

Light System

LED Light: 24pcs 16w Philips Lamp; 1200 Lux

Controlling System

Spray & Baking Switch, Light Switch, Emergency Stop, Breakdown Alarm

Fan pipe

700*700*910MM 4PC

Fireproof silicone wallboard

add $300

Let the light in the wallboard

Add$420

Water paint Air supply dry system

Add$1300

Photocatalytic waste gas treatment system

Add $3600

Stainless steel glass door

Add$1500

Fan pipe(0.91M,700*700)

Add:$40

Inhaling Ventilator  4kw

Add:$300
